1X9 Single-Mode Optical Transceiver
Features
1X9 Package Multi-Mode Transceiver
Single +3.3V or +5V Power Supply
LVPECL/PECL Data Interface, DC Coupling
Maximum Soldering Temerature&Time:240¡æ/10s
Compliant with Telcordia (Bellcore) GR-468-CORE
Fully Compliant with ITU-T G957, G958 Specifications
Eye Safety, Designed to Meet Laser Class 1, Compliant with IEC 60825-1
Low Cost,Low Power Consumption
RoHS Compliant Products Available
Product
| Part Number | Data Rate | Source | Wavelength | Voltage | Distance | Output Power | Sensitivity | Connector | Application |
| PTR2232 |
155Mb/s | FP | 1310nm | 5V | 20km |
-15¡«-8dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2232-3 |
155Mb/s | FP | 1310nm |
3.3V |
20km |
-15¡«-8dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2234 |
155Mb/s | FP | 1310nm |
5V |
40km |
-5¡«0dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2234-3 |
155Mb/s | FP | 1310nm |
3.3V |
40km |
-5¡«0dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2252 |
155Mb/s | FP | 1550nm |
5V |
20km |
-15¡«-8dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2252-3 |
155Mb/s | FP | 1550nm | 3.3V | 20km |
-15¡«-8dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR225D8 |
155Mb/s | DFB | 1310nm | 5V | 80km |
-5¡«0dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR225D8-3 |
155Mb/s | DFB | 1310nm | 3.3V | 80km |
-5¡«0dBm | ¡Ü-36dBm | SC,ST,FC | OC-3/STM-1/ Fast Ethernet |
| PTR2432 |
622Mb/s | FP | 1310nm | 5V | 20km |
-15¡«-8dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR2432-3 |
622Mb/s | FP | 1310nm | 3.3V | 20km |
-15¡«-8dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR2434 |
622Mb/s | FP | 1310nm | 5V | 40km |
-3¡«+2dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR2434-3 |
622Mb/s | FP | 1310nm | 3.3V | 40km |
-3¡«+2dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR245D8 |
622Mb/s | FP | 1550nm | 5V | 80km |
-3¡«+2dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR245D8-3 |
622Mb/s | FP | 1550nm | 3.3V | 80km |
-3¡«+2dBm | ¡Ü-28dBm | SC,ST,FC | OC-12/STM-4 |
| PTR2631 |
1.25GMb/s | FP | 1310nm | 5V | 15km |
-9¡«-3dBm | ¡Ü-22dBm | SC,ST,FC | Gigabit Ethernet |
| PTR2631-3 |
1.25GMb/s | FP | 1310nm | 3.3V | 15km |
-9¡«-3dBm | ¡Ü-22dBm | SC,ST,FC | Gigabit Ethernet |
| PTR263D4 |
1.25GMb/s | DFB | 1310nm | 5V | 40km |
-2¡«+3dBm | ¡Ü-23dBm | SC,ST,FC | Gigabit Ethernet |
| PTR263D4-3 |
1.25GMb/s | DFB | 1310nm | 3.3V | 40km |
-2¡«+3dBm | ¡Ü-23dBm | SC,ST,FC | Gigabit Ethernet |
| PTR265D8 |
1.25GMb/s | DFB | 1550nm | 5V | 80km |
-2¡«+3dBm | ¡Ü-24dBm | SC,ST,FC | Gigabit Ethernet |
| PTR265D8-3 |
1.25GMb/s | DFB | 1550nm | 3.3V | 80km |
-2¡«+3dBm | ¡Ü-24dBm | SC,ST,FC | Gigabit Ethernet |
| PTR265D100 |
1.25GMb/s | DFB | 1550nm | 5V | 100km |
¡Ý0dBm | ¡Ü-32dBm | SC,ST,FC | Gigabit Ethernet |
| PTR265D100-3 |
1.25GMb/s | DFB | 1550nm | 3.3V | 100km |
¡Ý0dBm | ¡Ü-32dBm | SC,ST,FC | Gigabit Ethernet |
| PTR2832 |
2.5Gb/s | FP | 1310nm | 3.3V/5V | 2m |
-9¡«-3dBm | ¡Ü-18dBm | SC,ST,FC | OC-48/STM-16 |
| PTR283D2 |
2.5Gb/s | DFB | 1310nm | 3.3V/5V | 15km |
-5¡«0dBm | ¡Ü-18dBm | SC,ST,FC | OC-48/STM-16 |
| PTR285D4 |
2.5Gb/s | DFB | 1550nm | 3.3V/5V | 40km |
-2¡«+3dBm | ¡Ü-18dBm | SC,ST,FC | OC-48/STM-16 |
| PTR285D8 | 2.5Gb/s | DFB | 1550nm | 3.3V/5V | 80km |
¡Ý0dBm |
¡Ü-18dBm | SC,ST,FC | OC-48/STM-16 |
1. Add Capital ""F"" at the End of Part # for RoHS Compliant (Lead Free)Products.
2.The Distance Listed Above is Recommended for Reference.
