100G QSFP28 SR/LR/ER/ZR
Product introduction： QSFP28 100G family are new generation of 100G transceiver modules solution based on QSFP fo...
-
100G QSFP28 4ch SR/LR/ER/ZR
Product introduction：QSFP28 100G family are new generation of 100G transceiver modules solution based on QSFP form...
CISCO OneX Converter Module
Like the move from GBIC to SFP the move from X2 to SFP+ seems inevitable, but currently there are four standa...
XENPAK to SFP+ converter for Cisco switches
This converter module converts a 10 Gigabit Ethernet XENPAK port into a 10 Gigabit Ethernet SFP+ port. It give...
40Gbps QSFP+ LoopBack modules
Loopback module in a QSFP form factor.The tinout QSFP loopback provides 4 pairs of transmit data channels connected...
| Package Form | Part No. | Fiber Type | Data Rate Range | Wavelength | Reach | Port |
| QSFP28 | PL100GPAM4SR | MMF | 100G | 850nm | 100m | LC |
| QSFP28 | PL100GQSFPSR4 | MMF | 100G | 850nm | 100m | MPO |
| QSFP28 | PL100GQSFPDR1 | SMF | 100G | 1310nm | 500m | LC |
| QSFP28 | PL100GQSFPFR1 | SMF | 100G | 1310nm | 2km | LC |
| QSFP28 | PL100GQSFPPSM4-02 | SMF | 100G | 1310nm | 2km | MPO |
| QSFP28 | PL100GQSFPCW4-02 | SMF | 100G | CWDM4 | 2km | LC |
| QSFP28 | PL100GQSFPPSM4-10 | SMF | 100G | 1310nm | 10km | MPO |
| QSFP28 | PL100GQSFPLR1 | SMF | 100G | 1310nm | 10km | LC |
| QSFP28 |
PL100GQSFPER1 |
SMF |
100G |
1310nm |
40km |
LC |
| QSFP28 | PL100GQSFPCW4-10 | SMF | 100G | CWDM | 10km | LC |
| QSFP28 | PL100GQSFPLR4 | SMF | 100G | LAN WDM (COB) | 10km | LC |
| QSFP28 | PL100GQSFPLR4 | SMF | 100G | LAN WDM (box) | 10km | LC |
| QSFP28 | PL100GQSFPRX10 | SMF | 100G | LAN WDM | 10km | LC |
| QSFP28 | PL100GQSFPLR4-DR | SMF | 100G/112G | LAN WDM | 10km | LC |
| QSFP28 | PL100GQSFPLR4-20 | SMF | 100G | LAN WDM | 20km | LC |
| QSFP28 | PL100GQSFPLR4-40 | SMF | 100G | LAN WDM | 40km | LC |
| QSFP28 | PL100GQSFPER4/I | SMF | 100G | LAN WDM | 40km | LC |
| QSFP28 | PL100GQSFPZR4/I | SMF | 100G | LAN WDM | 80km | LC |
| QSFP28 |
PL100GQSFPZR100 |
SMF |
100G |
LAN WDM |
100km |
LC |
-
100G QSFP28 4ch SR/LR/ER/ZR
Product introduction：QSFP28 100G family are new generation of 100G transceiver modules solution based on QSFP form factor. They are compliant with MSA and the IEEE 802.3ba. D...
40G QSFP+ Copper Cable
QSFP+ (Quad Small Form-factor Pluggable Plus) Cable Assemblies are suitable for very short distances and offer a highly cost-effective way to establish a 40-Gigabit link betwe...
