100G QSFP28 SR/LR/ER/ZR
Product introduction£º QSFP28 100G family are new generation of 100G transceiver modules solution based on QSFP fo...
-
100G QSFP28 4ch SR/LR/ER/ZR
Product introduction£ºQSFP28 100G family are new generation of 100G transceiver modules solution based on QSFP form...
-
CISCO OneX Converter Module
Like the move from GBIC to SFP the move from X2 to SFP+ seems inevitable, but currently there are four standa...
-
XENPAK to SFP+ converter for Cisco switches
This converter module converts a 10 Gigabit Ethernet XENPAK port into a 10 Gigabit Ethernet SFP+ port. It give...
-
40Gbps QSFP+ LoopBack modules
Loopback module in a QSFP form factor.The tinout QSFP loopback provides 4 pairs of transmit data channels connected...
Features and Benefits:
• Support for 40GBASE Ethernet
• Hot-swappable input/output device that plugs into a 40-Gigabit Ethernet QSFP+ Cisco switch port
• Flexibility of interface choice
• Interoperable with other IEEE-compliant 40GBASE interfaces available in various form factors
• Support for "pay-as-you-populate" model
• Support for the Cisco quality identification (ID) feature which enables a Cisco switch to identify whether the module is certified and tested by Cisco
• Small profile is easy to handle and minimizes air flow:
• Light weight (10 m cable weighs ~ 180g)
• Flexible cable with 35mm bend radius and cable diameter of 3.3mm
• Profile maximizes air flow relative to copper cables to reduce cooling cost and save energy
• QSFP form-factor for enhanced electrical/mechanical performance:
• Improved signal integrity relative to CX4 connector
• Improved connection stability and ruggedness relative to CX4
• Low incremental power consumption relative to passive copper cables:
• 0.9 W typical per end (1.8 W end to end)
• Low lantency:
• Latency compatible to passive copper cable solution
• Low electromagnetic interference
• ROHS compliant
Dimensions:
• Maximum outer dimensions for the QSFP+ connector module are (H x W x D): 13.5 x 18.4 x 72.4 mm.
• QSFP+ connector module typically weigh 100 grams or less.
Operating temperature range:
• Commercial temperature range: 0 to 70¡æ (32 to 158¡ãF)
• Storage temperature range: -40 to 85¡æ (-40 to 185¡ãF)
-
10G SFP+ DAC CABLES
Tinout stocks a large selection of SFP+ cables, including passive SFP+ cables, active SFP+ cables and SFP+ active optical cables. Our 10G SFP+ Cables offer customers a wide va...
-
SFP+ Twinax Cable 3m, Passive|SFP-H10GB-CU3M
¡ñ SFP+ to SFP+ Connetor¡ñ Copper Passive¡ñ 3 Meters¡ñ AWG24/AWG30¡ñ Compliant to SFP MSA ¡ñ Low power consumption ¡ñ Excellent EMI performance ¡ñ High reliabil...
